Karcher HD 5/12 CX PLUS Professional Pressure Washer 175 Bar
The Kärcher HD 5/12 CX Plus is a professional pressure washer designed for tradespeople and commercial operators requiring reliable, efficient cleaning performance. Delivering 175 bar maximum pressure with a 500 l/h flow rate, this 2.5kW pressure washer is built to tackle demanding tasks across construction sites, automotive workshops, and facility maintenance applications.
Engineered for professional use, the HD 5/12 CX Plus features an integrated hose reel for rapid deployment and storage of the 15 metre high-pressure hose, minimising setup time between jobs. The versatile dual-position operating mode allows the machine to be used vertically for easy manoeuvrability or horizontally for maximum stability, with wheels that lock automatically in the horizontal position.
Typical applications include vehicle washing, façade cleaning, floor and wall preparation, and equipment degreasing. The EASY!Force trigger gun reduces operator fatigue during extended use, whilst the EASY!Lock quick connection system enables fast accessory changes. On-board storage compartments keep the triple nozzle, Dirtblaster rotary nozzle, spray lance, and power cable organised and protected.
Manufactured to professional standards with premium components including a high-quality brass cylinder head, the HD 5/12 CX Plus is rated for 1-2 hours continuous daily use. The large, easily accessible water filter protects the pump from debris, whilst automatic pressure relief extends component service life. Supplied with a 1-year on-site warranty, this professional-grade pressure washer is suitable for trades, industries, and commercial facilities requiring dependable cleaning equipment.
Features and Benefits:
• EASY!Force trigger gun reduces operator fatigue during extended cleaning tasks
• EASY!Lock quick connection system enables fast accessory changes
• Integrated hose reel with 15 metre high-pressure hose for rapid deployment
• Dual-position operation allows vertical use for mobility or horizontal for maximum stability
• Wheels lock automatically in horizontal position for enhanced stability
• Integrated carry handle facilitates easy loading and transport
• Push handle retracts at the press of a button for compact storage
• Practical nozzle compartments keep triple nozzle and rotary nozzle organised
• Automatic pressure relief protects components and extends service life
• High-quality brass cylinder head ensures durability and reliable performance
• Large, easily accessible water filter protects pump from dirt particles
• On-board storage for nozzles, power cable, hose and lance keeps equipment secure
Specifications:
Voltage: 240V
Power Rating: 2.5kW
Cable Length: 5m
Hose Length: 15m
Flow Rate: 500 l/h
Working Pressure: 120 bar
Max. Pressure: 175 bar
Max. Water Feed Temperature: up to 60°C
Weight: 26kg
Dimensions (L x W x H): 380mm x 370mm x 930mm
Continuous Use Rating: 1-2 hours daily
Applications:
Automotive workshops and vehicle cleaning
Façade cleaning and building maintenance
Construction site equipment and area cleaning
Floor and wall surface preparation
Outside areas and yard maintenance
Vehicle fleets and machinery washing
Machine and device degreasing
Contents:
HD 5/12 CX Plus pressure washer unit
EASY!Force trigger gun
15m high-pressure hose
840mm spray lance
Triple nozzle
Dirtblaster rotary nozzle
Pressure Washer Help
To help determine the type of pressure washer required it is important to consider the size of your cleaning task and level of duty, i.e. how big is the cleaning object and how often will you need to clean it? Below is an explanation of the two main types of pressure washer. Whilst bar pressure is important the overriding factor in cleaning power is the water flow rate. More water = better cleaning.
Jargon Buster:
• Bar or PSI: Bar is the most common measure of pressure. PSI = bar x 14.5.
• Bar (max): This is the pressure achieved when the machine is first turned on
• Bar (rated) pressure: This is the operating water pressure of the machine.
• Motor size (kW): Motor size indicates power providing the machine runs efficiently.
• Flow Rate (l/h): Higher flow rates enable you to clean large areas or objects faster
Did You Know:
Pressure Washers use up to 80% less water than garden hosepipes.
Pressure Washers are not subject to hosepipe bans if used for safety reasons, or if a suction hose is used to pull water from a harvested source. i.e. not the water mains. They are also not subject to a ban if used for commercial reasons, for example to maintain cleanliness, hygiene or company image.
Important things to remember when using your pressure washer:
• Always use an RCD when using electrical products in connection with water.
• Never use a non-return valve at the pressure washer connection to a hose pipe.
• Never drive over or lay items on high pressure hoses to avoid damage.
• Your water supply hose should be a min of several meters long and unwound from its reel.
• If you are using an extension lead, check that it is rated at min of 13 amps and fully unwound from its reel.
