Trend Large Bevel Panel Raiser Router Cutter

This Trend Large Bevel Panel Raiser Router Cutter features a 50mm diameter cut, 17mm cut length, and 1/2" shank, offering a slightly smaller profile suited to more refined panel moulding and narrower frame-and-panel door sections.

With a 10° bevel angle, this cutter produces a subtler, more contemporary raised panel profile. It runs best between 12,000 and 18,000 RPM and matches Trend's range of profile scribers for a seamless joint. Suitable for both natural timber and MDF.

For best results when joining sections to create solid wood panels, alternate the growth ring direction of adjacent boards to prevent cupping. Always cut across the end grain first — any breakout will be removed when cutting with the grain.

Features and Benefits:
• 10° bevel angle for a refined, contemporary raised panel profile
• Compatible with Trend profile scribers (Ref. PSC/5)
• Suitable for natural timber and MDF
• Operates at 12,000–18,000 RPM for optimal finish quality
• Designed for heavy-duty routers in fixed overhead or inverted positions
• 1/2" shank for secure, stable fitment

Specifications:
Diameter Cut: 50mm
Cut Length: 17mm
Shank Diameter: 1/2"
Dia2 Metric: 16mm
Overall Length: 55.1mm
Angle: 10°
