Sealey Lifting Chain Block

The Sealey CB3000 delivers a substantial 3 tonne lifting capacity, designed for demanding industrial and construction applications. This heavy-duty model is ideal for lifting large machinery, substantial structural components, and other heavy loads requiring professional-grade lifting equipment with exceptional reliability.

Fitted with a heat-treated and ground triple-spur geared shaft and pinion, the CB3000 provides smooth, controlled operation even when handling maximum capacity loads. The mechanical load brake ensures loads remain safely secured during positioning and installation work. All chains are manufactured from hardened alloy material, delivering the strength and durability essential for heavy industrial use.

Load hooks feature safety latches to prevent accidental load release, whilst the compacted gear housing design maintains operational versatility even in areas with restricted vertical clearance. This makes the CB3000 particularly valuable in industrial workshops, fabrication facilities, and construction sites where substantial lifting capacity must be combined with compact, manoeuvrable equipment.

Features and Benefits:
• 3 tonne capacity for heavy industrial lifting tasks
• Mechanical load brake for secure load control
• Heat-treated triple-spur gearing for reliable heavy-duty operation
• Hardened alloy chains provide exceptional strength
• Compacted housing for use in limited headroom situations

Specifications:
Brand: Sealey
Capacity: 3000kg
Head Room: 554mm
Hook Aperture: 35mm
Load Chain Diameter: Ø7.1mm
Maximum Hook Capacity Ø: 50mm
Nett Weight: 25kg
Pulling Effort: 385N
Safe Working Load: 3000kg
Size (W x D): N/A
Standard Lift: 3m
