Trend CRAFTPRO Bearing Guided Combination Raised Bevel Router Cutter

The Trend CRAFTPRO Bearing Guided Combination Raised Bevel Router Cutter is a profile scriber set designed for producing classic cabinet panelled doors and drawer fronts on a router table.

This combination-type cutter is reassembled on the arbor to switch between cutting the profile and the scribe, allowing both parts of the joint to be completed with a single tool. The raised bevel design delivers the traditional panel door aesthetic favoured by cabinet makers and skilled joiners.

Suitable for router table use only, this cutter requires a medium or heavy duty router when used with the 1/4 inch shank. For certain routers, the base aperture may need to be enlarged to accommodate the cutter. A workholding device should be used when cutting the scribe on rail ends, and cutting edges must be staggered relative to one another.

Features and Benefits:
• Combination type design — reassemble the arbor to switch between profile and scribe cuts
• Cuts both parts of the joint with a single tool, reducing tooling costs
• Bearing guided for accurate, consistent results against the workpiece
• 10° raised bevel angle delivers a classic cabinet door profile
• 41mm diameter with 17mm cut length, suited to standard cabinet door rail and stile stock

Specifications:
Shank Diameter: 1/4 inch
Diameter: 41mm
Cut Length: 17mm
Overall Length: 81mm
Bearing Diameter: 22mm
Angle: 10°
